Welch CRVpro16 XPRF Vacuum Pump With Explosion-Proof Motor

$5,960.00

  • Ships wired for 115v/60hz but motor can be re-wired for 230v/60hzAs with all vacuum pumps with explosion proof motors, conduit wiring to an explosion proof control panel is required.
  • Always use a certified electrician for proper installation of vacuum pump to meet your local municipal codes.
  • cUL listed(E485334)



In stock

Vacuum Pump With Explosion Proof Motor CRVpro16 XPRF

  • Welch CRVpro16 XPRF is a 12.8 CFM rotary vane vacuum pump with an explosion proof motor. Total Ultimate pressure is 2 x10⁻³ Torr.
  • This pump is an ideal pairing for Cascade’s CVO-5-EX flammable solvent vacuum ovens.
  • Vacuum pumps with explosion proof motors are commonly used in petrochemical, chemical, and oil extraction facilities requiring motors needing to meet Class I, Groups C&D and/or Class II, Groups E, F&G requirements.

CRVpro16 – XPRF Motor


  • Ships wired for 115v/60hz but motor can be re-wired for 230v/60hz
  • As with all vacuum pumps with explosion proof motors, conduit wiring to an explosion proof control panel is required. Always use a certified electrician for proper installation of vacuum pump to meet your local municipal codes.
  • cUL listed(E485334)

MODEL

CRVpro 16

CAT.No.

3166E-01

POWER REQUIREMENTS

110-120V, 10.9A / 208-240V,
5.4A, 60Hz, 1Ph

FREE AIR DISCPLACEMENT

12.8 CFM (363 lpm)

Need vacuum connection kits?  Pump Oil? We have all of the vacuum accessories needed for the CRVpro vacuum pump.

Need a turnkey C1D2 rated vacuum oven system?  Cascade’s CVO-5-EX TURBO & DOUBLE UP Packages pair our certified flammable solvent vacuum pump with the CRVpro XPRF vacuum pump.  Ask us for details.
